AUDIO AMP CO Super Reverb

The classic BF Super Reverb is overall a different beast in tone, compared to the smaller BF amps. It moves a lot of cubic air through his four 10″ speakers; its OT has much more iron on it and it runs generally on a higher B+ voltage than most other BF amps. All these features give it a distinctive tone and volume, the amp stays longer clean and overdrives different when pushed harder or played louder.

As with its smaller brother, many things can be improved and optimised in its circuit and layout. Another big advantage of it is the Middle control knob in the »Vibrato« channel, it offers more tone control and a better, more flexible EQ than on all other and smaller BF amps, except of BF Twin Reverb. A BF Super Reverb is a distinctive experience to play through.

Der klassische BF Super Reverb ist grundsätzlich ein ganz anderes Biest was »Ton« betrifft, speziell wenn man ihn mit kleineren BF Modellen vergleicht, er bewegt, kubisch gesehen, sehr viel Luft durch seine vier 10″ Lautsprecher, sein Ausgangsübertrager hat die größere Kerndimensionierung und der gesamte Verstärker läuft mit einer höheren Versorgungsspannung als die kleineren BF Modelle. Alle diese Unterschiede verleihen ihm einen sehr speziellen Ton, er bleibt länger clean und übersteuert anders, wenn man etwas weiter aufdreht oder anbläst.

So wie auch bei seinem kleineren Bruder können viele Dinge bzgl. der Schaltung und des Schaltungslayouts verbessert werden.

Ein weiterer großer Vorteil, den er gegenüber den anderen Modellen, außer dem Twin Reverb hat, ist der »Mitten« Regler im »Vibrato« Kanal, er bietet mehr Kontrolle und einen flexibleren EQ als alle anderen, kleineren BF Modelle.

Durch und mit einem BF Super Reverb zu Spielen ist eine Erfahrung, die man unbedingt mal haben sollte.

Specs

  • Circuit: Classic BF style circuit, improved & optimised
  • Rectifier: GZ 34/5AR4
  • Power Amp: 2×6L6GC, Class A/B push/pull, 45W RMS
  • Bias Circuit: adjustable negative grid bias
  • Driver/PI stage: 12AT7/ECC81
  • Vibrato stage: 12AX7/ECC83
  • Reverb driver: 12AT7/ECC81
  • Reverb mix: 12AX7/ECC83
  • Input stage VCh 7025/E83CC
  • Input stage NCh 7025/E83CC
  • Controls: Intensity, Speed, Bass, Middle, Treble, Volume, Bass, Treble, Volume, Bright on/off (both channels)
  • Inputs: Vibrato Hi and Lo (-6dB), Normal Hi and Lo (-6dB)
  • Output: two parallel speaker outputs
  • Output Z: 2Ω (others on request)
  • Features: Bias test jacks, 4mm banana type, MERCURY MAGNETICS® USA »Tone Clone« transformers

Options

  • 10″ or 12″ speakers
  • Available as Head or 1×12″, 2×12″, 2×10″ or 4×10″ Combo (lightweight solid spruce)
  • Mid cut switch for Normal channel
  • Adjustable negative grid bias or cathode bias switch
  • Hot rodded Normal channel
  • EQ voicing (BF, Dumble, Tweed or British)
  • Improved »Middle« control
  • Reverb & Tremolo on both channels
  • No tremolo built in
  • Line Out
  • Colour of pilot lamp lens (red, amber, blue, green or purple)
  • Colour/shape of control knobs
  • Strap handle style and type
